Product Information:

ICI Mace Snagging Tester is used to determine the tendency of fabrics to snag in normal wear with mace balls randomly bouncing on rotating cylinders rapidly. Viewing Cabinet is for the assessment of snagging grades.

Specimen is sewed into sleeves and placed on a cylindrical drum. Then a mace (spiked ball with 11 nails) bounces randomly against the rotating specimen. Snags are produced to a degree affected by a variety of factors. The degree of fabric snagging is then evaluated by comparison of the tested specimens with visual standards that may be either fabrics or photographs of fabrics. Complete with viewing cabinet and assessment photographs.

Test Scope:

Testing the Knitted and woven fabrics and other fabric prone to snag, especially applied to the filament and textured yarns fabric

Testing Standards:

ASTM D3939、GB/T 11047、JIS L1058

Consumables:

Tungsten carbide point; Felt Sleeves

Specification:

ICI Mace Snagging Tester:

a)     Touchscreen Control

b)     Rotating Cylinder: 4 pcs

c)      Rotation Speed: 60 rpm

d)     Mace ball: 4 sets (Included bronze ball, tungsten carbide point & Chain)

e)     Felt Sleeve: 4 sets

f)       Cutting Template: 2 pcs

h)     Distance Setting Gauge: 1 pc

i)       Power Supply: AC230V, 50Hz/60Hz

j)       Dimension: 750(L) ×630(W) ×550(H)mm

k)      Weight: ICI Mace Snagging Tester: approx. 54kg

Viewing Cabinet:

1.     LED Light：The specially designed viewing cabinet can be used for rating of snagging under the normal light source in laboratory.

2.     Rating Template: 2 pcs

3.     Rating Photographs: 9 photos (rated from grade 1 to 5)

4.     Dimension: 500(L) ×640(W) ×540(H) mm

5.     Weight: approx. 30kg

Order information:

RF308N      ICI Mace Snagging Tester

RF308/1      Viewing Cabinet

RF308/2      Tungsten carbide point (pack of 12 pcs)

RF308/3       Felt Sleeve (pack of 4 pcs)

RF308/4       Snagging Photographs (set of 10 pcs)

RF308/5       Mace Ball (Including bronze ball, tungsten carbide point & Chain)
